Digital Storage Oscilloscopes
₹21,500
Product Code :
| Bandwidth | 500 MHz |
|---|---|
| Channels | 4 Channel |
| Sample Rate | 100 MSa/s |
| Memory Depth | 10 Mpts |
| Display Size | 7 inch |
| Vertical Sensitivity | 2 mV/div |
| Interface | RS232 |
| Trigger Mode | Edge |
-
25MHz/50MHz/75MHz/100MHz Bandwidth
-
7 Inch Color TFT-LCD Display, 480*234
-
500MSa/Sec Sampling Rate
-
Channels:2CH+1EXT
-
Memory Depth: 32kpts
-
6 digits hardware Frequency Counter, real time counting display
-
Support SCPI programming command control
-
Interface: USB Device ,USB Host, RS-232, Pass/Fail
-
Unique digital filter and data recorder function
-
Embedded 12 languages, online help, one key storing and one key printing
-
Vertical Sensitivity: 2mV ~ 10V/Div
-
8 Bit Vertical Resolution
-
Trigger Source: CH1,CH2,Ext,Ext/5,AC Line
-
Trigger Type: Edge, Pulse, Video, Slope, Alternative
-
Math Operation: +,-,*,/,FFT
