Double Beam Uv Vis Spectrophotometer
₹249,000
Product Code :
| Optical Type | Double Beam |
|---|---|
| Wavelength Range | 190-1100 nm |
| Instrument Type | Benchtop |
| Spectral Bandwidth | 1 nm |
| Display Type | LCD |
| Sample Holder | Standard Cuvette |
| Usage Area | Pharma Lab, Chemical Lab, Environmental Lab, Clinical Lab, Food Lab, Academic Lab |
| Interface | USB |
|
Spectral Bandwidth |
1nm |
|
Optical System |
Double Beam Grating 1200 lines/mm |
|
Wavelength Range |
190-1100 nm |
|
Wavelength Accuracy |
±0.3nm |
|
Wavelength Repeatability |
±0.2nm |
|
Photometric Range |
±0-200%T, -0.3~3A, 0-9999C |
|
Photometric Accuracy |
0.2%T(0~100%T), ±0.002A(0-0.5A), ±0.004A(0.5-1A) |
|
Photometric Repeatability |
≤0.15%T (0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A) |
|
Photometric Mode |
T, A, C, E |
|
Stray Light |
+0.03%T@220nm, 360nm |
|
Stability |
±0.0003A/h @ 500 nm |
|
Baseline Flatness |
±0.001A @ 500nm |
|
Noise |
0.001A@500nm |
|
Scanning Speed |
Fast, Medium, Low (Max. 3000nm/min) |
|
Wavelength Setting |
Automatic |
|
Display |
7" TFT Color Screen |
|
Light Source |
Deuterium & Tungsten lamp |
|
Detector |
Silicon Photodiode |
|
Cell Holder |
10mm single cell holder (sample & reference) |
|
Output |
USB,RS232C |
|
Power supply |
AC 220V/50Hz |
|
Pakcing Dimension (LxWx H) |
880 x 690 x 520 mm |
|
Gross Weight |
30kg |
