LPG Gas Meter
₹15,500
Product Code :
| Meter Type | Diaphragm |
|---|---|
| Meter Size | G6 |
| Flow Range | 0.04-6 m³/h |
| Connection Size | 1.5 inch |
| Pressure Rating | 0.5 kPa |
| Accuracy Class | Class 2.0 |
| Mounting | Pipeline |
| Display Type | Mechanical |
ApplicationG4 type gas meter for measuring natural gas, LPG and other non-corrosive gases.Features and Benefits:
- Flow rate of 6m3/h
- Synthetic diaphragm
- Reed switch with pulse output
- Pressed zinc-coated steel plate body
Specifications:
- Meter Type: G4
- Body Material: pressed zinc-coated steel plate
- Diaphragm: synthetic
- Minimum flow rate: 0.04 m3/h
- Maximum Flow Rate: 6 m3/h
- Cyclic volume: 1.2 dm3
- Maximum pressure: 0.5 bar
- Connections: 32mm ISO228
- Temperature Range: -10 to +40 Degree C
